stamping parts

NO.	Name	model	description
001	Connecting piece	NTLJP001	Dimensions: 30 × 7 × 2.5mm aperture: Φ5.2mm mounting hole center distance: 21mm Material: T2 copper
002	Connecting piece	NTLJP002	Dimensions: 18 × 13 × 2mm Installation center distance: 9 mm Material: T2 copper
003	Connecting piece	NTLJP003	Dimensions: 31 × 7 × 2 mm Aperture: Φ5.2 mm mounting hole center distance: 21 mm Material: T2 copper nickel-plated
004	Connecting piece	NTLJP004	Dimensions: 31 × 11 × 1.5mm aperture: Φ6.2 mm mounting hole center distance: 19.5 mm Material: 59 brass
005	Connecting piece	NTLJP005	Dimensions: 77 × 30 × 2 mm Aperture: Φ5.2 mm mounting hole center distance: 70 mm Material: T2 copper
006	Connecting piece	NTLJP006	Dimensions: 66 × 19 × 16 mm Aperture: Φ6.2 mm mounting hole center distance: 54 mm Material: T2 copper
007	Connecting piece	NTLJP007	Dimensions: 18 × 13 × 1.5 mm aperture: Φ4.2 mm Material: T2 copper nickel-plated
008	Connecting piece	NTLJP008	Dimensions: 15 × 8 × 7mm 59 brass
